🗺️ Visual Odometry (VO) — One-Month Project Plan

A structured 4-week plan to implement a feature-based VO system from scratch. Aligned with classical VO architecture:

• Image Sequence
• Feature Detection
• Feature Matching
• Motion Estimation
• Local Optimization

📆 Week-by-Week Plan

✅ Week 1: Setup & Feature-Based VO Prototype

🎯 Goal: Get a working pipeline from image input to trajectory output.

• Set up development environment (Python + OpenCV + NumPy).
• Choose and load dataset (e.g., KITTI, EUROC, or your own camera).
• Load monocular or stereo frames.

Implement:

• Feature extraction (e.g., ORB or SIFT).
• Feature matching (e.g., FLANN or brute-force matcher).
• Estimate motion:
  • Essential matrix with Five-Point RANSAC.
  • Recover pose (rotation + translation).
• Triangulate 3D points from matched features.
• Visualize 2D/3D trajectory (Matplotlib / Open3D).

✅ Deliverable: Basic VO pipeline with visual trajectory on dataset.

✅ Week 2: Improve Robustness & Accuracy

🎯 Goal: Make the pipeline more robust and less sensitive to noise.

• Replace brute-force matching with:
  • KLT tracker (e.g., cv2.calcOpticalFlowPyrLK), or
  • Efficient matcher with ratio test.
• Add a motion model or frame-to-frame filtering.
• Tune RANSAC threshold to reduce outliers.
• Add scale recovery (using stereo baseline or known motion if monocular).

✅ Deliverable: Smoother and more consistent VO output across sequences.

✅ Week 3: Add Optimization & Visual Backend

🎯 Goal: Optimize motion estimation over multiple frames.

• Add a pose graph or keyframe-based structure.
• Integrate Bundle Adjustment:
  • Use libraries like g2o or Ceres Solver.
• Optimize poses and 3D landmarks together.
• Keyframe selection/culling: keep one every N frames or when motion exceeds threshold.

✅ Deliverable: Refined, consistent map and camera trajectory.

✅ Week 4: Evaluation + Real-Time Extension

🎯 Goal: Evaluate system, improve performance, and test real-time capability.

• Compare estimated trajectory with ground truth using:

  • ATE (Absolute Trajectory Error)
  • RPE (Relative Pose Error)

• Plot error metrics and visualize drift.

• Optional:

  • Integrate IMU for better scale estimation.
  • Run real-time VO using a USB/RPi camera.
  • Add a basic ROS2 wrapper around the pipeline.

• Finalize code:

  • Write README, add example scripts.
  • Record and share video demos.

✅ Deliverable: Shareable, reproducible VO system with error plots and visual output.

🔧 Tools & Libraries Used

• Python 3, OpenCV
• NumPy, Matplotlib, Open3D
• g2o / Ceres (for optimization)
• Optional: ROS2, IMU tools

💡 Tip: You can extend this pipeline toward SLAM by adding loop closure detection and global optimization later.
